AL400RLBV

Power Supply/Charger with LED Cable Assembly, 12 or 24VDC @ 4A, Board

Altronix AL400RLBV power supply/charger converts a 220VAC, 50/60Hz input into a single 12VDC or 24VDC output. It also offers a suite of features that includes AC fail supervision, battery presence, and low battery supervision. Includes LED cable assembly and LED lens.

Specifications

  • Input
    • Voltage: 220VAC (working range 198VAC - 256VAC), 50/60Hz, 1.5A max.
    • Input fuse rated 5A/250V.
  • Output
    • Voltage: 12VDC or 24VDC selectable
    • Current: 4A @ 12VDC or 3A @ 24VDC continuous max.
    • Other: Short circuit and thermal overload protection
    • Filtered and electronically regulated output.
  • Battery Charging
    • Type: Sealed lead acid or gel type
    • Fuse Rating: 15A/32V
    • Failover: Upon AC loss, instantaneous
    • (Batteries are sold separately).
  • Supervision
    • AC Failure: Form "C" contacts
    • Battery: Form "C" contacts
  • Indicators (LED)
    • Input 220VAC is present
    • DC Output: Powered
    • Battery: Discharged or not connected
  • Electrical
      • Temperature:
        • Operating: 0° C to 49° C (32° F to 120° F).
        • Storage: - 20° C to 70° C ( - 4° F to 158° F).
    • Relative Humidity: 85% +/- 5%.
      • BTU/Hr. (approx.):
        • 12VDC: 25 BTU/Hr.
        • 24VDC: 37 BTU/Hr.

Agency Listings


CE Compliant

Dimensions & Weight

Dimensions (approximate):
  • 4.5"W x 7.1"L x 1.44"H (114.3 mm W x 180.3 mm L x 36.6 mm H).
Weights (approximate):
  • Product Weigtht: 0.65 Lbs. (0.29 kg).
  • Shipping Weigtht: 0.8 Lbs. (0.36 kg).
