NetWay81G

PoE Midspan, 8 Port, 10/100/1000, 30W max per port (240W total power), Battery Charging, 115/230VAC Input

Altronix NetWay81G is an 8 port midspan in a 1U rack enclosure. It provides PoE/PoE+ (up to 30W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup.

Specifications

  • Input
    • 115VAC 60Hz, 3.25A or 230VAC 50/60Hz, 2A
  • Power
    • Unit provides PoE / PoE+
    • 30W full power per port
    • Total power: 240W
  • Ethernet
    • Connectivity: RJ45, auto-crossover
    • Wire type: 4-pair CAT5e or better structured cable
    • Distance: up to 100m
    • Speed: 10/100/1000 BaseT, half/full duplex, auto negotiation
  • Functions
    • Auto detection and protection of legacy non-PoE cameras/edge devices.
  • Battery Charging
    • Built-in battery charger (optional rack mount battery enclosure - RE2).
    • Automatic switchover to stand-by battery when AC fails.
    • (Batteries are sold separately).
  • Temperature
    • Operating: - 20° C to 50° C ( - 4° F to 122° F).
    • Storage: - 20° to 70° C ( - 4° F to 158° F).
    • Relative Humidity: 85% +/- 5%.
    • BTU/Hr. (approx.): 123 BTU/Hr.
    • Operating Altitude: Up to 2,000m.

Agency Listings


CE Compliant

Accessories

Name Description
NetWayXT Ethernet Extender, 1 Port, 10/100, Passes PoE, Extends Data additional 100m
NetWayXTX Ethernet Extender, 1 Port, 10/100, Passes PoE/PoE+, Extends Data additional 100m
RE2 Rack Mount Battery Enclosure, 2U

Dimensions & Weight

Enclosure:
  • Modular 1U standard EIA 19" rack mount chassis.
  • Dimensions 19.12"W x 1.62"H x 8.5"D (486 mm W x 42 mm H x 216 mm D).
Weights (approximate):
  • Product Weigtht: 6.17 Lbs. (2.8 kg).
  • Shipping Weigtht: 7.5 Lbs. (3.4 kg).
