Specifications
Input
- 6VDC applications use TP1640.
- 12VDC applications use T2428100.
- 24VDC applications use T2428175.
Output
- 6VDC, 12VDC or 24VDC selectable output.
- 4A supply current.
- Filtered and electronically regulated outputs.
- Short circuit and thermal overload protection.
Battery Charging
- Built-in charger for sealed lead acid or gel type batteries.
- Maximum charge current 0.3A.
- Zero voltage drop when switching over to battery backup.
- (Batteries are sold separately).
Visual Indicators
- AC input and DC output LED indicators.
Electrical
Temperature:
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage: - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity: 85% +/- 5%.
BTU/Hr. (approx.):
- 6VDC: 13 BTU/Hr.
- 12VDC: 25 BTU/Hr.
- 24VDC: 49 BTU/Hr.
System AC input VA requirement:
- 6VDC: 55.2VA.
- 12VDC/24VDC: 115VA.
Features
- Extremely compact design.
- Includes battery leads.
- Snap Track compatible (order Altronix model number ST3).
Dimensions & Weight
Dimensions (approximate):
- 3"W x 3.5"L x 2"H (76.2 mm W x 88.9 mm L x 50.8 mm H).
Weights (approximate):
- Product Weigtht: 0.35 Lbs. (0.158 kg).
- Shipping Weigtht: 0.45 Lbs. (0.204 kg).
