INTEGRATION
ACCESS & POWER
Access and Power Integration Designed for Smaller
Installations and Retrofit Applications.

TM250
Compact Access & Power Solution
- Supports a single Altronix power supply/charger and Mercury boards
for access systems or up to two (2) EP1501 or MR51e (without power).
- Ideal for above door, retrofit installations.
- Accommodates a single 12VDC/4AH battery.
TM400 TM250
Customizable Access & Power Solution
- Supports a single Altronix power supply/charger with Altronix sub-assemblies
and various Mercury boards.
- Accommodates the following options:
1- Up to three (3) MR50 with one (1) Altronix power supply/charger.
2- One (1) EP1501 or MR51e and one (1) EP4502, EP1502, MR52,
MR16IN or MR16OUT with one (1) Altronix power supply/charger.
3- One (1) EP4502, EP1502, MR52, MR16IN or MR16OUT with
one (1) Altronix power supply/charger, up to two (2) Altronix sub-assemblies.
- Accommodates up to two (2) 12VDC/7AH batteries.
TM400

Boards sold separately.
