NetWay8GL

Network Managed PoE Midspan, 8 Port, 10/100/1000, 60W max per port (240W total power), Battery Charging, 115/230VAC Input

Altronix NetWay8GL is an 8-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE (up to 60W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embedded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere.

  • Input
    • 115VAC, 60Hz, 5A or 230VAC, 50Hz, 3.5A.
  • Power
    • Unit provides PoE / PoE+ / Hi PoE.
    • 60W max per port, not to exceed 240W total power.
    • Total power: 240W.
    • IEEE 802.3af and IEEE 802.3at compliant.
    • Short circuit protection.
  • Ethernet
    • Eight (8) ports for cameras/edge devices over ethernet.
    • Wire type: 4-pair CAT5e and higher.
    • Speed: 10/100/1000 Mbps.
  • Functions
    • Auto detection and protection of legacy non-PoE cameras/edge devices.
  • Battery Charging
    • Built-in battery charger (optional rack mount battery enclosure - RE2).
    • Automatic switchover to stand-by battery when AC fails.
    • (Batteries are sold separately).
  • LINQ Technology
    • SSL (Secure Socket Layer) security encryption.
    • User level security.
    • Built-in IP management allows for remote camera reset and monitoring.
    • Provides local and/or remote access to critical information via LAN/WAN
    • Email and Windows Dashboard Alert notifications report real-time diagnostics.
    • Event log tracks history.
  • Temperature
    • Operating: - 20ºC to 40ºC ( - 4ºF to 104ºF).
    • Storage: - 20º to 70ºC ( - 4ºF to 158ºF).
    • Relative Humidity: 85% +/- 5%.
    • BTU/Hr. (approx.): 246 BTU/Hr.
  • Operating Altitude
    • - 304.8 to 3,048m.
Enclosure:
  • Modular 1U standard EIA 19" rack mount chassis.
  • Dimensions 19.12"W x 1.62"H x 8.5"D (486 mm W x 42 mm H x 216 mm D).
Weights (approximate):
  • Product Weight: 6.17 Lbs. (2.8 kg).
  • Shipping Weight: 7.5 Lbs. (3.4 kg).
