ACCESS AND POWER INTEGRATION SOLUTIONS

For up to 8 door DMP access systems
Trove1DM1 - Enclosure + Backplane
• Includes Altronix Trove1 Enclosure TDM1 backplane .
For up to 16 door DMP access systems
Trove2DM2 - Enclosure + Backplane
• Includes Altronix Trove2 Enclosure and TDM2 backplane .
Accommodates
• The following DMP boards with or without
Altronix power/sub-assemblies:
- 708, 734, 734N 65
- Altronix Power Supplies/Sub-Assemblies
TDM1 - Backplane
• Accommodates same as above and fits Altronix Trove1 enclosure .
TDM2 - Backplane
• Accommodates same as above and fits Altronix Trove2 enclosure .
TDMD2 (optional) - Door Backplane Trove1DM1
• Accommodates DMP boards * Boards not included
- XR150, XR550, 714-8, 714-16 . All registered trademarks are
• Fits Altronix Trove2 and Trove3 enclosure . property of their respective owners .
Door Backplane Dimensions: 23 .75”H x 18”W x 0 .5”D
TDMD2
Pre-assembled kits available in various configurations. * Boards not included
