PD8TCB

Power Distribution Module, 8 PTC Outputs up to 57VDC, Board

Altronix PD8TCB power distribution module is designed to distribute a single input up to 57VDC into eight (8) PTC protected outputs.

  • Input
    • Voltage Range: Up to 57VDC
  • Outputs
    • Eight (8) Eight (8) PTC protected outputs (auto-resettable) 3.75A per output max.
    • Total output current should not exceed max current rating of power supply employed
    • PTCs are rated @ 3.75A/72V.
  • Visual Indicators
    • Power On green LED indicator.
  • Temperature
    • Operating: 0° C to 49° C (32° F to 120° F).
    • Storage: - 20° C to 70° C ( - 4° F to 158° F).
  • Relative Humidity
    • 85% +/– 5%
  • Mounting hardware is included
    Dimensions (approximate):
    • 3.25"W x 5.25"L x 1"H (82.55 mm W x 133.35 mm L x 25.4 mm H).
    Weights (approximate):
    • Product Weight: 0.25 Lbs. (0.11 kg).
    • Shipping Weight: 0.3 Lbs. (0.14 kg).
