Configure Your Trove

Easily Integrate Altronix Power with Access Controllers and Accessories
from the Industry's Leading Manufacturers
Trove Home Trove1 Trove1R Trove2R Trove1WP Trove2 Trove3 Trove3B TM400 TM250
trove group

News Flash… Altronix lead time for all Trove Access & Power Integration kits are now 15 days max.

Configurations are UL Listed in the U.S. and Canada.

Trove3

(36.12"H x 30.125"W x 7.06"D)
Options
Board Names
Icons
Install Door Backplane

Door backplane is available for this manufacturer. ?

Door backplane is not available for this manufacturer

Import Configuration Request Design Assistance

Select an Access Control Manufacturer:

Back Print Export

Bill of Materials:

Back Clear Import Bill of Materials Assistance

Drag and Drop Components into Highlighted Positions:

996035PCBK

Integriti Access Controller (IAC)

996001EUPCBK

Integriti Security Controller (ISC)

996500PCBKIT

UniBus 8 Zone Expander

996515PCBKIT

UniBus 8 Relay Auxiliary Expander

996005PCBKIT

8 Zone LAN Expander

996018PCBK

Intelligent LAN Access Module (ILAM) / Aperio-SimonsVoss-Salto Interface

996535PCBK

UniBus 2 Door / 2 Reader Expander

996012PCBK

Standard LAN Access Module (SLAM)

996540PCBK

UniBus 16 Floor Lift Interface device

AL400ULXB2

12VDC @ 4 amp, 24VDC @ 3 amp
(field selectable)

AL600ULXB

12VDC or 24VDC @ 6 amp
(field selectable)

AL1012ULXB

12VDC @ 10 amp

AL1024ULXB2

24VDC @ 10 amp

eFlow4NB

12VDC or 24VDC @ 4 amp
(field selectable)

eFlow6NB

12VDC or 24VDC @ 6 amp
(field selectable)

eFlow102NB

12VDC @ 10 amp

eFlow104NB

24VDC @ 10 amp

Tango1B stackable

PoE Driven Power Supply with Lithium Battery Backup

VR6

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

VR10

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

PSC1

Power Supply/Charger Cover

AL400XB2V

12VDC @ 4 amp, 24VDC @ 3 amp
(field selectable)

AL600XB220

12VDC or 24VDC @ 6 amp
(field selectable)

AL1012XB220

12VDC @ 10 amp

AL1024XB2V

24VDC @ 10 amp

eFlow4NBV

12VDC or 24VDC @ 4 amp
(field selectable)

eFlow6NBV

12VDC or 24VDC @ 6 amp
(field selectable)

eFlow102NBV

12VDC @ 10 amp

eFlow104NBV

24VDC @ 10 amp

Tango1B stackable

PoE Driven Power Supply with Lithium Battery Backup

VR6

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

VR10

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

PSC1

Power Supply/Charger Cover

ACM4

Four (4) fuse protected outputs.
Fire Alarm Interface.

ACM4CB

Four (4) PTC protected outputs.
Fire Alarm Interface.

ACM8

Eight (8) fuse protected outputs.
Fire Alarm Interface.

ACM8CB

Eight (8) PTC protected outputs.
Fire Alarm Interface.

ACMS8

Dual Input.
Eight (8) fuse protected outputs.
Fire Alarm Interface.

ACMS8CB

Dual Input.
Eight (8) PTC protected outputs.
Fire Alarm Interface.

ACMS12

Dual Input.
Access Power Controller
12 Fuse Protected Outputs

ACMS12CB

Dual Input.
Access Power Controller
12 PTC Protected Outputs

PD4UL

Four (4) fuse protected outputs.

PD4ULCB

Four (4) PTC protected outputs.

MOM5

Five (5) PTC protected outputs.
Fire Alarm Interface

PD8UL

Eight (8) fuse protected outputs.

PD8ULCB

Eight (8) PTC protected outputs.

PDS8 stackable

Dual Input. Eight (8) fuse protected outputs.

PDS8CB stackable

Dual Input. Eight (8) PTC protected outputs.

PDS16 stackable

Dual Input. Eight (16) fuse protected outputs.

PDS16CB stackable

Dual Input. Eight (16) PTC protected outputs.

VR6

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

VR10

Voltage Regulator. Converts 24VDC input into 5VDC or 12VDC output.

LINQ2

Network Communication Module
for eFlow Power Supply/Chargers

NetWay5A

5-Port Switch Board
(10/100)

NetWay5B

5-Port Switch Board
(10/100/1000)

Trove3SWC

Trove Compatible Battery/Wire Enclosure

Trove3BWC

Trove Compatible Battery/Wire Enclosure

RSB1

Single Rocker Switch Bracket

RSB2

Two Rocker Switch Bracket

WM5

Magnetic Cable Tie Mounts
Pack of 5

WM25

Magnetic Cable Tie Mounts
Pack of 25

WM100

Magnetic Cable Tie Mounts
Pack of 100

MM4

Mounting Magnets
Pack of 4

MM8

Mounting Magnets
Pack of 8

MM12

Mounting Magnets
Pack of 12

MM24

Mounting Magnets
Pack of 24

BL3

Battery Leads, 18 inch

BL4

Battery Lead, 8 inch

BL6

Battery Leads, 68 inch

BT1212

BT1212

Rechargeable Battery, Sealed lead acid (SLA), 12VDC, 12AH

BT126

BT126

Rechargeable Battery, Sealed lead acid (SLA), 12VDC, 6AH

BTL125

BTL125

Rechargeable Lithium Iron Phosphate (LiFePO4) Battery

eFlow4NB

12VDC or 24VDC @ 4 amp
(field selectable)

eFlow6NB

12VDC or 24VDC @ 6 amp
(field selectable)

eFlow102NB

12VDC @ 10 amp

eFlow104NB

24VDC @ 10 amp

eFlow4NBV

12VDC or 24VDC @ 4 amp
(field selectable)

eFlow6NBV

12VDC or 24VDC @ 6 amp
(field selectable)

eFlow102NBV

12VDC @ 10 amp

eFlow104NBV

24VDC @ 10 amp

LINQ2

Network Communication Module
for eFlow Power Supply/Chargers
