P. 36

ACCESS

                          ™
                            NETWORK COMMUNICATION MODULES

                             Control, Monitor and Report eFlow Power
       LINQ2
       • Control, monitor and report power/diagnostics from anywhere over the network .
       • Each LINQ2 is compatible with one (1) or two (2) eFlow power supply/chargers .
       Status Monitoring Functions:             Setup:
       •  DC output voltage                     •  Site ID identifies installation location
       •  Output current draw                   •  Power supply/charger calibration
       •  AC status                             •  DC output(s) control
       •  Battery status                        •  Relay control - remotely operate HVAC,
    36 •  Unit temperature                        lighting or security systems


        Features:
        •  UL Listed Sub-Assembly in the U .S . for Access Control, Burglar and Fire,  •  Event log tracks history .
          UL Listed Sub-Assembly in Canada for Access Control and Burglar .  •  Secure Socket Layer (SSL) .
        •  Provides local and/or remote access to critical information   •  Reduces system downtime, eliminates service calls   LINQ2
          via LAN/WAN to help keep systems up and running at optimal levels .    and creates RMR opportunities .
        •  Control eFlow power output(s) locally or remotely .  •  Programmable via USB or web browser .
        •  Two (2) integral network controlled Form “C” Relays .  •  Includes operating software and 6ft . USB cable .
        •  Email and Windows Dashboard Alert notifications report
          real-time power diagnostics .



                                                                               888.258.7669
                 ®
