Provide Remote Indications of BBU & BDAS Status.
ANC1BBU
Remote Annunciator for COMMBATT1 EMERGENCY
- Allows local and remote annunciation of various trouble conditions
of BDA (Bi-Directional Amplifier) and BBU (Battery Back-Up Unit).
- Reports conditions to the FACP through separate set of dry contacts,
with visual and audible indicators.
- Nine (9) 10K EOL supervised inputs to connect to power supply and
other equipment that require annunciation of trouble conditions.
- Ten (10) NC output contacts to connect to FACP with convenient
end of line resistor wiring terminals. COMMUNICATIONS
- Separate relay NC output for reporting common trouble to FACP.
- Two (2) spare outputs for additional equipment monitoring.
- 12-24VDC input.
- Bicolor visual indicators of trouble conditions:
- AC Fail, Low Battery, Charger Fail, Component Fail, Ground Fault ANC1BBU
BDA Fail and Antenna Fail
Agency Listings:
- UL2524: Standard for In-building 2-Way Emergency Radio Communication Enhancement Systems
- UL864: Standard for Control Units and Accessories for Fire Alarm Systems.
- CAN/ULC-S527 Fourth Edition, 2019 Control Units for Fire Alarm Systems.
