FIRE POWER
NAC Power and Notification with all the Bells and Whistles.
PROGRAMMABLE

FIRESWITCH108
Network Programmable NAC Power Extender
- 24VDC regulated power-limited NAC outputs at 10A max.
- 2.5A max. current per output.
- One (1) dedicated aux. output with battery backup rated at 1A.
- Two (2) configurable inputs trigger via Class A or Class B
signal circuits (polarity reversal) or dry contacts.
- Power outputs are programmable as:
- 8 Class B NAC outputs
- 4 Class A NAC outputs
- Aux. power outputs (with or without battery backup)
- Any combination of the above
- EOL resistor values are programmable by output, saving time and labor costs. FireSwitch108
- Sync protocols include Potter/Amseco, Gentex®,
System Sensor®, and CooperWheelock®.
- Ethernet port and LCD display facilitate local programming and remote status monitoring.
- Temporal Code 3, Steady Mode, Input to Output Follower Mode.
- Temporal Code 4 for system CO alarms.
- Signal circuit trouble memory - quickly locates intermittent system
trouble and eliminates costly and unnecessary service calls.
- Synchronize up to twelve (12) FireSwitch108 units.
- Compatible with 12VDC or 24VDC fire panels.
- Input to output follower mode.
- Embedded LINQ™ Technology allows for remote device reset, system monitoring, and reporting.
