Page 25 - New Products Brochure
P. 25
Fire Power, when Wall Space is not an Option...
R1002ULADA
Rack Mount NAC Power Extenders
- Programmable Supervised Indicating Circuit Outputs:
Four (4) Class B, or two (2) Class A, or RACK
One (1) Class A and Two (2) Class B.
AL1002ULADA - Wall Mount Version
R1042ULADA
Rack Mount NAC Power Extenders
- Programmable Supervised Indicating Circuit Outputs:
Four (4) Class B, or Four (4) Class A, or
Two (2) Class A and Two (2) Class B. NAC POWER
AL1042ULADA - Wall Mount Version
R1042ULADA
Features:
- Provides 24VDC at 10A (2.5A per output).
- Sync protocols include Potter/Amseco, Gentex®, System Sensor®, and CooperWheelock®.
- Two (2) Aux outputs rated at 1A each.
- Two (2) Class A or two (2) Class B inputs.
- Two (2) NC dry contact trigger inputs.
- Temporal Code 3, Steady Mode, Input to Output Follower Mode.
- Built-in battery charging
(RE2R - rack mount battery enclosure, houses four 12VDC/7AH batteries).
- Ground fault detection.
RE2R
25
