Monitor Activity in any Area...
Provide Situational Awareness, while Reducing Risk.

TEMPOA2
Occupancy Alert System
- Continuously monitor normal traffic patterns to provide notifications of unauthorized activity.
- Ideal for single use restrooms/spaces commonly found in retail, hotels, dining,
medical facilities, universities, transportation, parks/recreational facilities, etc...
- Activate via deadbolt latch monitor, motion sensor, contacts, and more... OCCUPANCY
- Provides visual and/or audible, or remote alerts
- Trigger options:
- Two (2) Door Sensor/Trigger inputs.
- Two (2) Strobe “Steady” Trigger Inputs.
- Two (2) Strobe “Flash” Trigger Inputs.
- Two (2) “Panic/Emergency” Trigger Inputs. TEMPOA2B
- Output options:
- 12VDC/2.5A, 24VDC/1.25A, (30W). ALERT
- Two (2) Strobe Switched Power Outputs.
- Four (4) Aux. Power Outputs.
- 24VAC input
- Built-in battery charging
- LCD display simplifies programming.
- Momentary and/or latching events.
- Visual LED Indicators for AC Power, DC Output and active Trigger.
- Embedded LINQ™ Technology option, TEMPOA2X
allows for remote device reset, system monitoring, and reporting.
TEMPOA2X includes transformer and line cord, 115VAC input
