ACCESS

®
PANIC DEVICE POWER CONTROLLERS
StrikeIt1 StrikeIt2:
• UL Listed in the U .S . and Canada for Access Control and CSFM Approved . • UL Listed in the U .S . and Canada for Access Control
• Two (2) 20VDC to 26 .4VDC individually controlled lock outputs and CSFM Approved .
for applications with battery backup . • One (1) 24VDC controlled lock output rated @ 16 amp for 300ms .
24VDC for applications without battery backup (U .S . only) . • One (1) 24VDC regulated auxiliary output rated @ .5 amp .
• Current rating 15 amp for 300ms, 0 .75 continuous supply current . • One (1) N/O trigger input .
• One (1) 20VDC to 26 .4VDC aux . output rated at 0 .75 amp for • LED indicates presence of 24VDC .
applications with battery backup . 24VDC for applications • Fits two (2) 12VDC/4AH batteries .
(in U .S .) not requiring battery backup . Enclosure dimensions: 8 .25”H x 7 .5”W x 3 .5”D
• Selectable timed lock release from 1 sec . to 30 seconds .
• One (1) 12VDC filtered and regulated output rated @ 0 .75 amp .
• Two (2) delayed follower relays control automatic door operators . 99
• Two (2) follower relays can be used to indicate doors have been released .
• Two (2) programmable Fire Alarm Disconnect options:
a) Removes power to outputs and disables delayed follower relays .
b) Connects power to lock outputs and enables delayed follower relays .
• LED indicators monitor: lock status, lock wiring trouble
conditions (open or short circuit), FACP trigger input and battery .
• Fits two (2) 12VDC/7AH batteries . StrikeIt1
Enclosure dimensions: 13 .5”H x 13”W x 3 .25”D
Features:
• Designed to handle the high current surge panic hardware • Short circuit and thermal overload protection .
locking device(s) demand . • AC power LED indicator .
• Built-in charger for sealed lead acid or gel type batteries . • 115VAC 50/60Hz . input .
• Automatic switch over to stand-by battery when AC fails . • Includes cam lock and battery leads .
